Fully Automatic Horizontal Baler

Name: Fully Automatic Horizontal Baler
Brand: ENERPAT
Rating: 5.0 (42 reviews)

The ENERPAT HBA Series Auto Tie Baler is a fully automatic horizontal baler built for recycling centers and manufacturing plants processing large, continuous volumes of cardboard, plastics, film, woven bags, and industrial waste.
Three-way hydraulic compression forms dense, uniform bales, and once a bale reaches the length you've set, the machine ties it off automatically, eliminating the need for an operator standing by to bundle each one.
It's proven at scale: BMW Brilliance runs a customized HBA auto tie horizontal baler for cardboard at 8 tons/hour, and industrial waste recycling centers push the auto tie baler up to 20 tons/hour.

Why ENERPAT HBA:

Fully automatic tying: set your bale length, the machine handles the rest
Three-way compression for dense, well-formed bales
Adopting German auto-tie technology with high-strength quenched wire
Siemens/Schneider PLC, touchscreen control, real-time monitoring
CE certified, plug-in ready, no complex site setup
Free material testing before you order

Quantity:
Availability:





Inquiry Add to Basket Visit Time

Model:
HBA
Brand:
ENERPAT

Fully Automatic Horizontal Baler auto tie horizontal baler auto tie baler automatic tying baler Horizontal Waste Baler automatic paper baler auto cardboard baler

Description

Video

Details

FAQ

Testimonials

auto tie horizontal baler

ENERPAT Auto Tie Horizontal Baler

The ENERPAT HBA series is an auto tie horizontal baler, also known as an automatic tying baler or automatic horizontal baling press machine. Unlike a manual or semi-automatic horizontal baler that needs an operator to bundle each finished block, the HBA's automatic tying system closes and secures every bale on its own, so one machine can keep up with continuous high-volume input.

Material feeds into the hopper chamber, where a three-way compression mechanism (three hydraulic cylinders working in coordination with the main ram) forms it into a dense, evenly shaped bale. Once the bale reaches your set length, the auto-tie system wraps it in high-strength quenched steel wire and ejects it automatically. Core components come from established international brands: Schneider electricals, Siemens PLC, and Hallite cylinder seals.

As a horizontal waste baler, the HBA handles a wide range of materials: cardboard, waste paper, plastic bottles, film, woven bags, straw, and industrial or household waste. It is suitable for recycling companies, manufacturing plants, paper mills, and confidential-document destruction centers.

Operating Principle

Conveying and Feeding:

The material is transferred to the hopper chamber of the auto tie horizontal baler.

Hydraulic Compression:

The loose material is compressed under the drive of the hydraulic system.

Bale Ejection:

The bundling system automatically forms the material into bales and ejects them.

Product Specification Sheet

The fully automatic horizontal baler HBA range runs from 60 to 200 tons of press force and 22 to 55 kW of motor power, with bale weights from roughly 200 kg up to 1,300 kg depending on material and model. As a rough starting point:

Lower-volume operations, lighter material (light cardboard, plastic film): entry-level press force, smaller feed hopper
Mid-volume, mixed cardboard and plastics: step up press force and hopper size together. This is where most recycling centers land
High-volume, continuous processing: highest press force and motor power in the range, paired with a conveyor infeed

Bale weight and tying-wire count both scale up with the model, so heavier, denser bales generally call for a larger machine even at similar throughput. Send us your daily volume and material mix, and we'll confirm the right model with a free material test before you order.

Model	HBA60-7272	HBA60-11075	HBA80-11075
Press Force (tons)	60	60	80
Motor Power (kw)	22	22	37
Bale Size(mm)	720 × 720 × L	1100 × 750 × L	1100 × 750 × L
Bale Weight (OCC) (kg)	200-500	400-700	600-900
Machine Size (mm)	6770 × 3050 × 3580	6880 × 3850 × 3550	6880 × 3850 × 3550

Model	HBA100-110110	HBA120-110125	HBA150-110125	HBA200-110130
Press Force (tons)	100	120	150	200
Motor Power (kw)	45	55	2 × 45	2 × 55
Bale Size(mm)	1100 × 1100 × L	1100 × 1250 × L	1100 × 1250 × L	1100 × 1250 × L
Bale Weight (OCC) (kg)	800-1100	900-1200	1000-1300	1250-1350
Machine Size (mm)	8560 × 3950 × 4550	9250 × 4150 × 4850	10050 × 4100 × 4910	10050 × 4100 × 4910

Material Testing

This automatic paper and cardboard baler setup is equally capable on mixed plastics and general waste. The three-way compression handles loose, bulky, or irregular material that would be hard to bale consistently on a single-ram machine.

Not sure your material is a fit? We test customer-supplied samples free of charge before you order: Request Material Testing

Supported Materials:	Target Applications：
Waste paper, cardboard, and paper boxes Plastic bottles (PET, HDPE) and plastic film Dry straw and crop stalks Woven bags Foam Aluminum cans Household waste and general municipal waste Industrial waste	Paper Recycling Yards Material Recovery Facilities Logistics Hubs & Distribution Centers Paper Mills & Pulp Plants Auto Component Suppliers Department Store Central Depots Garment & Textile Factorie

The ENERPAT HBA series auto tie horizontal baler, also known as the auto tie baler or horizontal cardboard baler, operates in fully automatic bundling mode, reducing costs and increasing efficiency. Since its launch, this device has never received any complaints and has garnered widespread acclaim in the market. In the Chinese market, BMW factories were the first to adopt the ENERPAT fully automatic horizontal baler.

5 Key Core Advantages

Overall Structure

- Integrated, one-piece design. Transported as a complete unit, ready to run once fuelled and wired on-site
- Closely matched to real operating needs, straightforward for operators to run day to day
- Can be configured with a conveyor for automatic infeed, reducing manual loading labor
Three-Way Compression Structure

- Three hydraulic cylinders work in coordination with the main ram, two of them adjusting automatically as main-cylinder pressure changes
- Produces a dense, well-formed bale with consistent shape, even on loose or bulky material
Bundling Technology

- German automatic tying technology: stable, efficient, and built on imported core components
- High-strength quenched steel tying wire resists wear and corrosion, keeping bales tightly secured with no loosening in transit
Hydraulic System

- Cartridge-type valve group for high flow and fast cycle speed
- H-type tapered pipe fittings and Hallite (UK) seals, leak-resistant, safe, durable
- Industrial chiller runs 24/7, keeping oil temperature controlled to support continuous multi-shift operation
PLC Control System

- Siemens/Schneider PLC with touchscreen and button dual control, real-time monitoring of cycle time, current, and oil temperature
- One-click operation with automatic alarms for fast troubleshooting
- CE-certified safety system: emergency stop, oil-temperature alarm, overload protection, and lockable maintenance mode

FAQs

What are the main features of the ENERPAT HBA automatic horizontal baler?

It utilizes German automatic baling technology and high-strength tempered wire for secure bundling, making it suitable for packaging various materials.
Which industries and materials is this baler suitable for?

It is widely applicable in logistics, warehousing, manufacturing, and recycling, particularly for packaging cardboard, plastics, and metal scrap.
How is the quality of ENERPAT HBA components ensured?

It uses original components from globally recognized electrical brands like Siemens and Schneider, ensuring stable operation and reduced failure rates.
What is the warranty policy for this horizontal automatic baler?

It offers a 1-year warranty on the machine and a 5-year warranty on the motor, along with free material testing and design services for customer assurance.
What advantages does the ENERPAT manufacturer offer in after-sales service?

ENERPAT has a global service network, providing quick technical support and after-sales service to ensure timely assistance for customers.
